Focus on Avionics and Light-Armored Vehicle Displays
October 2nd 2018, Van Nuys, CA—IEE, a manufacturer of enhanced displays for military applications, will be exhibiting at the 2018 AUSA Annual Meeting and Exposition, Oct. 8th-10th in Washington, DC. IEE’s line of field-proven military displays includes a 10.1-inch Widescreen Ultra Extended Graphics Array (WUXGA) multi-function display (MFD) for fixed and rotary wing applications, and a 12.1-inch Smart-Touch CDU especially designed for ground vehicle applications.
The 10.1” MFD features state of the art digital video capabilities, and a heavy-duty, full color, very high-bright WUXGA high-resolution screen. The very wide viewing angle and selectable dual-mode LED backlight provide flexibility to assist the operator’s situational awareness. The interface also includes an 8-way joystick, encoder knobs, and thirteen programmable bezel pushbuttons to support a wide range of applications.
10.1” Display Technical Features:
• 10.1 inch WUXGA, (1920x1200) color TFT LCD Display
o Brightness: 1,100 cd/m2 typical
o Contrast Ratio: 800:1
o Viewing Angle: ± 85º H / ± 85º V
• Extensive array of operator controls on the sealed, backlit bezel
o 13 programmable bezel pushbuttons, with tactile feedback and NVIS filtered backlight (MIL-STD-3009)
o 3-way rotary switch for OFF/NIGHT/DAY, one brightness encoder, two programmable dual-concentric encoders and one 8-way joystick
o On-screen display (OSD) functions controlled using bezel keys
• Video Interface: 2 x HD-SDI (with loop-through), 2 x DVI-D
• Serial Communication Interface: RS-422
• Power: 28VDC per MIL-STD-704
• Environmental: MIL-STD-810F
• EMI: MIL-STD-461F
“IEE focuses on modularity and open standards in our design and engineering to support both forward looking technology and backward compatibility requirements that increase the longevity and flexibility of our display products,” said Steve Motter, Vice President of Business Development for IEE.
IEE’s displays for Light Armored Vehicles (LAVs) include a 12.1-inch Smart-Touch CDU with low latency video processing, expandable COTS open architecture, and Gigabit Ethernet networked processing. This display provides a basis for a wide range of current and future Vetronics architectures including the US Army VICTORY Architecture and NATO Generic Vehicle Architecture (GVA).
12.1” AMLCD Display Features:
• High Bright XGA display
• Armored resistive 5-wire touch-screen
• Intel x86 dual-core processor
• High-performance video and graphics processing
• Low latency video selection from multiple sources
• Frame grabber image capture
• Modular scalable design to match system architecture
• MIL-STD-810; MIL-STD-461; MIL-STD-1275
IEE is exhibiting at AUSA 2018, Oct. 8th-10th at the Walter E. Washington Convention Center, in Washington DC. Stop by booth #9220 or make an appointment with Steve Motter by calling toll-free 1-800-422-0867, ext. 327, or email firstname.lastname@example.org.
For over 70 years, Industrial Electronic Engineers, IEE, has been a trusted provider of enhanced displays for military and industrial applications. From rapid prototyping of custom designs to full-scale production runs, IEE produces innovative displays with advanced features like low-latency video processing, high-bright and NVIS backlighting, and lightweight, ruggedized enclosures. IEE’s direct control of critical process steps reduces costs, decreases production lead times and improves lifecycle management. IEE display products are distributed worldwide. Go to: https://ieeinc.com/.
